Description
If you own a Ram HD and you’ve spent any time researching front end parts, it’s likely you’ve heard ofCarli Ball Joints. Now that the research has begun and our customers are overloaded withinformation, what’s the benefit to these Carli Joints?
The main differentiators that matter – materials, process, and design. Our philosophy hasalways been to skip on the enumeration of materials and process and leave this to the engineers. As ourlifetime ball joints have been in circulation for many years and more competition enters the market,the “what makes these so special” question surfaces regularly; we’re happy to shed some light!
The Design
The factory design consists of a lower ball joint and upper floating king-pin. The upper is only a pivotpoint and sees lateral load, relying on a coated sleeve as the wear surface. The lower is a true ball andsocket with a composite liner that fails over time, requiring replacement.
Carli Joints improve this design with a floating king-pin upper where the pin “hat” contactsthe housing, creating a second wear surface and eliminating sleeve failure. The upper cavity is enlargedfor more grease reserve with a threaded cap and zerk fitting for serviceability. Channels in the pinpromote grease migration, while a Viton seal protects against contamination.
The lower Carli Joint features a recessed, angled Zerk for easy access without disassembly,grease channels, and no liners. A bronze wear surface, disc spring, safety washer, and snap ring keepeverything preloaded and tight. A rubber seal locks the housing to the pin for extra protection.
The Process
Carli Joints undergo an intensive process starting with copper masking, thencarburizing/heat treating for 20–25 thousandths of case-hardness. Competing processes(like salt-bath nitride) only reached ~3 thousandths. After stripping, the joints receive adry-lube gray coating for corrosion resistance and lubricity, paired with anti-seizeand Redline CV2 grease.
Lifetime Guarantee
Backed by the industry’s only Advanced Replacement Lifetime Guarantee, Carli Ball Jointsare replaced if play exceeds .040” vertical or .020” lateral. Simply provide a video and your purchasereceipt, and replacements are shipped with a return label. This ensures peace of mind and long-term support.
